Spray Nozzle IEC 60529 IPX3 IPX4


Introduction:

It's strictly designed according to IEC60529 Figure 5, Used to test the waterproof performance of appliance and electric appliance with the rain protection function.


Application:

The IPX3 IPX4 Hand-held Spray Nozzle intended for use on specimens that will not fit within the diameter of the Oscillating Tube Tester.

The difference between IPX3 and IPX4 is that the baffle should be removed in the IPX4 test.


Specifications:

No.

Item

Parameter

1

Water  supply

Water  flow rate is 0.05 ~ 0.15 Mpa clean water without inclusion.

2

Spray  nozzle parameters

External  diameter: Ф102 mm

spherical diameter: SФ75.5 mm

There is a middle hole and There are 24 holes in the internal circle of holes  of which the included angle is 30°.  There are 96 holes in the external circle of holes of which the included  angle is 15°. 121 holes in total.

The hole diameter: Ф0.5 mm

It is made of brass.

3

Reference

IEC60529  IPX3 IPX4.

4

Baffle

Removable

5

Pressure  gauge

0~0.25MPa

6

Site  requirements

Dedicated  IP waterproof test room, The ground should be flat with illumination, With  good function of inflow and drainage.
